  • Item No.:
    19" Standard Rack
    Product Name:
    Cabinet Rack Series
    Features:
    To manufacture must follow the ANSI/ EIARS-310-C,D,E,F criterions. UL & CE approved, and MIL-STD-167 test.
    ● Main Aluminum vertical rails were using the squeeze aluminum pillars; an arc type is its appearance; material :AL6063T5
    ● Flexible Aluminum vertical rails can set at the rack's front & back to meet the actual wire' needs. And it at least should have 3 faces of grooves. User can see their actual situation to added the cable dust. Rack's external depth is 900mm, and it's internal depth must reach 750mm.
    ● We have honeycomb or tempered glass door for you to choose. The same to the Front doors . And with the hidden lock or coded lock is optional and up to your actual need.
    ● 6-way Universal socket strips(1set) with switch, 50 Sets of Catch Nut and Panel Screw are the standard outfit, also you may added the earthling copper rails for your rack.
    ● Used the powder coating (it can against the rusty, oxidization, scrape hurts, lacquer peeling, strong acid and alkali' erosion) for all racks.
    ● If rack's width has to increase at 600mm, the flexible aluminum vertical rails still maintains at 19 inches.
    ● Rack side panel can be easy to assemble and disassemble from outside and without using any tools.
    ● Rack's appearance (front & gear doors, side panels) should be without any screws and nuts to affect its entirety looks.
    ● Two sets of UL & CE approved cooling fans as standard outfit. Fan's size is 120mm*25mm. Increasing the fans' quantity is optional.
    ● using the baying kits to make the steady for the rack and floor. using the baying kits to make the steady for the rack and floor.
    ● Using Ground-Support Standoff to fix the Rack on the ground, or install the Lockable Wheels in order to move the Rack at random.
    ● The Removable Aluminum Vertical Rails can be adjusted its depth forward or backward. As regards Catch Nuts installed in the steel rails, it can be also adjusted its height upper or down according to the position of rack-mount chassis.
    Dimension:
    Standard Size
    Standard Size
    H
    0
    H
    1
    D
    0
    D
    1
    15U
    JF-15-615
    667
    747
    529
    615
    20U
    JF-20-615
    889
    969
    529
    615
    25U
    JF-25-615
    1111
    1191
    529
    615
    30U
    JF-30-615
    1334
    1414
    529
    615
    35U
    JF-35-615
    1556
    1636
    529
    615
    41U
    JF-41-615
    1882
    1902
    529
    615
    15U
    JF-15-750
    667
    747
    664
    750
    20U
    JF-20-750
    889
    969
    664
    750
    25U
    JF-25-750
    1111
    1191
    664
    750
    30U
    JF-30-750
    1334
    1414
    664
    750
    35U
    JF-35-750
    1556
    1636
    664
    750
    41U
    JF-41-750
    1882
    1902
    664
    750
    15U
    JF-15-900
    667
    747
    814
    900
    20U
    JF-20-900
    889
    969
    814
    900
    25U
    JF-25-900
    1111
    1191
    814
    900
    30U
    JF-30-900
    1334
    1414
    814
    900
    35U
    JF-35-900
    1556
    1636
    814
    900
    41U
    JF-41-900
    1882
    1902
    814
    900
    41U
    JF-41-1100
    1867
    1947
    814
    900
    41U
    JF-41-1100
    1822
    1902
    1014
    1100
    42U
    JF-42-1000
    1867
    1947
    914
    100
    42U
    JF-42-1100
    1867
    1947
    1014
    1100
    H1 W/O Caster High( 85mm) , 1U= 1.75 Inch= 44.45mm
